Amate(Master) Audio
!

KEY serie

!

Key12a

!
  • Amplifier (program power): 450 W (LF) + 150 W (HF) – Class D bi-amplified
  • Input Sensitivity: 8 dBu
  • Input Impedance: 20 kΩ
  • Maximum input level: 20 dBu
  • Mains: Universal switch mode Power Supply 85-265 V / 45-65 Hz
  • Average current draw: 0.7 A (Heavy duty musical program)
  • Standby Mode Consumption: < 5 W
  • SPL (1m)
  • 124 dB continuous
  • 127 dB peak
  • Built-in DSP: 48 bit
  • Built-in delay line: 118 ms/ 40 m
  • AD/DA converters: 24 bit – 48 kHz
  • Frequency response (-10 dB): 50 Hz – 18 kHz
  • LF: 12″ woofer (2″ voice coil)
  • HF: 1″ Kevlar driver
  • Directivity (HxV): 70º x 40º
  • Dimensions (HxWxD): 608 x 420 x 405 mm
  • Weight: 20.1 kg
  • Multilayer Baltic birch plywood
  • Front steel grille with grey micro-foam cloth
  • High resistant black matt Polyurea paint

Key15a

!
  • Amplifier (program power): 450 W (LF) + 150 W (HF) – Class D bi-amplified
  • Input Sensitivity: 8 dBu
  • Input Impedance: 20 kΩ
  • Maximum input level: 20 dBu
  • Mains: Universal switch mode Power Supply 85-265 V / 45-65 Hz
  • Average current draw: 0.7 A (Heavy duty musical program)
  • Standby Mode Consumption: < 5 W
  • SPL (1m)
  • 125 dB continuous
  • 128 dB peak
  • Built-in DSP: 48 bit
  • Built-in delay line: 118 ms/ 40 m
  • AD/DA converters: 24 bit – 48 kHz
  • Frequency response (-10 dB): 48 Hz – 18 kHz
  • LF: 15″ woofer (2.5″ voice coil)
  • HF: 1″ Kevlar driver
  • Directivity (HxV): 70º x 40º
  • Dimensions (HxWxD): 688 x 474 x 440 mm
  • Weight: 23.2 kg
  • Multilayer Baltic birch plywood
  • Front steel grille with grey micro-foam cloth
  • High resistant black matt Polyurea paint

key8

!
  • Power (musical program): 240 W
  • Nominal impedance: 16 Ω
  • SPL (1m) 93 dB (1 W)
  • 117 dB continuous
  • 120 dB peak
  • Frequency response (-10 dB): 62 Hz – 20 kHz
  • LF 8″ Neodymium woofer (1.5″ voice coil)
  • HF 1″ Neodymium Titanium diaphragm tweeter
  • Directivity (HxV) 90º Conical
  • Dimensions (HxWxD): 450 x 295 x 280 mm
  • Weight: 9.5 kg
  • Finish: multilayer plywood
  • Front steel grille with foam
  • Black matte ecological paint

Key12

!
  • Power (musical program): 400 W
  • Nominal impedance: 8Ω
  • SPL (1m) 97 dB (1 W)
  • 123 dB continuous
  • 126 dB peak
  • Frequency response (-10 dB): 62 Hz – 20 kHz
  • LF 12″ Neodymium woofer (2″ voice coil)
  • HF 1″ Kevlar driver
  • Directivity (HxV) 70º x 40º
  • Dimensions (HxWxD): 608 x 420 x 405 mm
  • Weight: 18.7 kg
  • Finish: multilayer plywood
  • Front steel grille with foam
  • Black matte ecological paint

Key15

!
  • Power (musical program): 500 W
  • Nominal impedance: 8Ω
  • SPL (1m) 98 dB (1 W)
  • 125 dB continuous
  • 128 dB peak
  • Frequency response (-10 dB): 48 Hz – 20 kHz
  • LF 12″ Neodymium woofer (2,5″ voice coil)
  • HF 1″ Kevlar driver
  • Directivity (HxV) 70º x 40º
  • Dimensions (HxWxD): 688 x 474 x 440 mm
  • Weight: 21.9 kg
  • Finish: multilayer plywood
  • Front steel grille with foam
  • Black matte ecological paint

Key18Wa

!
  • Amplifier (program power): 1000 W (LF)– Class D bi-amplified
  • Input Sensitivity: 2 dBu
  • Input Impedance: 20 kΩ
  • Maximum input level: 20 dBu
  • Mains: Universal switch mode Power Supply 85-265 V / 45-65 Hz
  • Average current draw: 1 A (Heavy duty musical program)
  • Standby Mode Consumption: < 5 W
  • SPL (1m)
  • 127 dB continuous
  • 130 dB peak
  • Built-in DSP: 48 bit
  • Built-in delay line: 118 ms/ 40 m
  • AD/DA converters: 24 bit – 48 kHz
  • Frequency response (-10 dB): 34 Hz – 90/100/110 Hz
  • LF: 18″ woofer (4″ voice coil)
  • Directivity (HxV): Omnidirectional
  • Dimensions (HxWxD): 700 x 550 x 605 mm
  • Weight: 41.9 kg
  • Multilayer Baltic birch plywood
  • Front steel grille with grey micro-foam cloth
  • High resistant black matt Polyurea paint

Key18W

!
  • Power (musical program): 1000 W
  • Nominal impedance: 8Ω
  • SPL (1m) 97 dB (1 W)
  • 127 dB continuous
  • 130 dB peak
  • Frequency response (-10 dB): 34 Hz – 150 kHz (with external Amate Audio DSP)
  • LF 18″ woofer (4″ voice coil)
  • Directivity (HxV): Omnidirectional
  • Dimensions (HxWxD): 700 x 550 x 605 mm
  • Weight: 39.9 kg
  • Finish: multilayer plywood
  • Front steel grille with foam
  • Black matte ecological paint

Key15W

!
  • Power (musical program): 600 W
  • Nominal impedance: 8Ω
  • SPL (1m) 95 dB (1 W)
  • 123 dB continuous
  • 126 dB peak
  • Frequency response (-10 dB): 38 Hz – 180 kHz (with external Amate Audio DSP)
  • LF 15″ woofer (3″ voice coil)
  • Directivity (HxV): Omnidirectional
  • Dimensions (HxWxD): 600 x 490 x 520 mm
  • Weight: 27.1 kg
  • Finish: multilayer plywood
  • Front steel grille with foam
  • Black matte ecological paint

Accesoires

!

fc-key12 flightcase 2x key12/a

!
  • Deze flightcase is geschikt voor 2 Amate Audio KEY12 of KEY12A luidsprekers

fc-key15 flightcase 2x key15/a

!
  • Deze flightcase is geschikt voor 2 Amate Audio KEY15 of KEY15A luidsprekers

fc-key15w flightcase 2x key15w

!
  • Deze flightcase is geschikt voor 2 Amate Audio KEY15W Subwoofers

fc-key18 flightcase 2x key18w/a

!
  • Deze flightcase is geschikt voor 2 Amate Audio KEY18W of KEY18WA Subwoofers

Joker serie

!

JK26a

!
  • Amplifier (program power): 400 W (LF) + 50 W (HF) Class D bi-amplified
  • Input Sensitivity: 8 dBu 1.94 V
  • Input Impedance: 20 kΩ
  • Maximum input level: 20 dBu
  • Mains: Universal switch mode Power Supply 85-265 V / 45-65 Hz
  • Average current draw: 0.6 A (Heavy duty musical program)
  • Standby Mode Consumption: 5 W
  • SPL (1m) 121 dB continuous, 124 dB peak
  • Built-in DSP: 48 bit, Presets FLAT / NEARFIELD / SPEECH / XOPOLE / XOALL
  • Built-in delay line: 118 ms/ 40 m
  • AD/DA converters: 24 bit – 48 kHz
  • Frequency response (-10 dB): 58 Hz – 20 kHz
  • LF: 2x 6” Neodymium woofers with carbon fiber cone (1.5” voice coil), HF: 1” Neodymium titanium diaphragm tweeter
  • Directivity (HxV): 90º x 90º
  • Dimensions (HxWxD): 532 x 250 x 260 mm
  • Weight: 9.5 kg
  • Multilayer Baltic birch plywood
  • 1.5 mm optimized steel grille with foam
  • High resistant bi-component black Polyurea® coating

JK46a

!
  • Amplifier (program power): 600 W (LF) + 100 W (HF) – Class D bi-amplified
  • Input Sensitivity: 8 dBu – 1.94 V
  • Input Impedance: 20 kΩ
  • Maximum input level: 20 dBu
  • Mains: Universal switch mode Power Supply 85-265 V / 45-65 Hz
  • Average current draw: 0.7 A (Heavy duty musical program)
  • Standby Mode Consumption: < 5 W
  • SPL (1m)  125 dB continuous, 128 dB peak
  • Built-in DSP: 48 bit Presets  FULL RANGE / NEARFIELD / NEARFIELD+ /SPEECH / XOVER
  • Built-in delay line: 118 ms/ 40 m
  • AD/DA converters: 24 bit – 48 kHz
  • Frequency response (-10 dB): 50 Hz – 19 kHz
  • LF: 4x 6” Neodymium woofers with carbon fiber cone (1.5” voice coil), HF: 1.75” PETP diaphragm neodymium driver
  • Directivity (HxV): 50º to 100º x 55º
  • Dimensions (HxWxD): 1052 x 250 x 260 mm
  • Weight: 18.5 kg
  • Multilayer Baltic birch plywood
  • 1.5 mm optimized steel grille with foam
  • High resistant bi-component black Polyurea® coating

JK10a

!
  • Amplifier (program power): 600 W (LF) + 100 W (HF) – Class D bi-amplified
  • Input Sensitivity: 8 dBu – 1.94 V
  • Input Impedance: 20 kΩ
  • Maximum input level: 20 dBu
  • Mains: Universal switch mode Power Supply 85-265 V / 45-65 Hz
  • Average current draw: 0.7 A (Heavy duty musical program)
  • Standby Mode Consumption: < 5 W
  • SPL (1m), 125 dB continuous, 128 dB peak
  • Built-in DSP: 48 bit, Presets FLAT / NEARFIELD / NEARFIELD+ / LONGTHROW / SPEECH / XOPOLE / XOALL
  • Built-in delay line: 118 ms/ 40 m
  • AD/DA converters: 24 bit – 48 kHz
  • Frequency response (-10 dB): 50 Hz – 18 kHz
  • LF: 10” Neodymium woofer (2.5” voice coil), HF: 1.4” PETP diaphragm driver
  • Directivity (HxV): 50º x 100º x 55º
  • Dimensions (HxWxD): 539 x 365 x 340 mm
  • Weight: 14.6 kg
  • Multilayer Baltic birch plywood
  • 1.5 mm optimized steel grille with foam
  • High resistant bi-component black Polyurea® coating

JK12a

!
  • Amplifier (program power): 600 W (LF) + 100 W (HF) – Class D bi-amplified
  • Input Sensitivity: 8 dBu – 1.94 V
  • Input Impedance: 20 kΩ
  • Maximum input level: 20 dBu
  • Mains: Universal switch mode Power Supply 85-265 V / 45-65 Hz
  • Average current draw: 0.7 A (Heavy duty musical program)
  • Standby Mode Consumption: < 5 W
  • SPL (1m) 126 dB continuous, 129 dB peak
  • Built-in DSP: 48 bit, Presets FLAT / NEARFIELD / NEARFIELD+ / LONGTHROW / SPEECH / XOPOLE / XOALL
  • Built-in delay line: 118 ms/ 40 m

  • AD/DA converters: 24 bit – 48 kHz
  • Frequency response (-10 dB): 48 Hz – 19 kHz
  • LF: 12” woofer (3″ voice coil), HF: 1.75” PETP diaphragm Neodymium driver
  • Directivity (HxV): 50º x 100º x 55º
  • Dimensions (HxWxD): 609 x 410 x 405 mm
  • Weight: 22.7 kg
  • Multilayer Baltic birch plywood
  • 1.5 mm optimized steel grille with foam
  • High resistant bi-component black Polyurea® coating

JK15a

!
  • Amplifier (program power): 600 W (LF) + 100 W (HF) – Class D bi-amplified
  • Input Sensitivity: 8 dBu – 1.94 V
  • Input Impedance: 20 kΩ
  • Maximum input level: 20 dBu
  • Mains: Universal switch mode Power Supply 85-265 V / 45-65 Hz
  • Average current draw: 0.7 A (Heavy duty musical program)
  • Standby Mode Consumption: < 5 W
  • SPL (1m) 127 dB continuous, 130 dB peak
  • Built-in DSP: 48 bit, Presets FLAT / NEARFIELD / NEARFIELD+ / LONGTHROW / SPEECH / XOPOLE / XOALL
  • Built-in delay line: 118 ms/ 40 m
  • AD/DA converters: 24 bit – 48 kHz
  • Frequency response (-10 dB): 45 Hz – 19 kHz
  • LF: 15” Neodymium woofer (3″ voice coil), HF: 1.75” PETP diaphragm Neodymium driver
  • Directivity (HxV): 50º x 100º x 55º
  • Dimensions (HxWxD): 689 x 460 x 450 mm
  • Weight: 23.5 kg
  • Multilayer Baltic birch plywood
  • 1.5 mm optimized steel grille with foam
  • High resistant bi-component black Polyurea® coating

JK26

!
  • Power (musical program): 400 W
  • Nominal impedance: JK26/8 8 Ω – JK26/16 16 Ω
  • SPL (1m) 95 dB (1 W), 121 dB continuos, 124 dB peak
  • Frequency response (-10 dB): 70 Hz – 20 kHz
  • LF 2x 6” Neodymium woofers with carbon fiber cone (1.5” voice coil)
  • HF 1” Neodymium Titanium diaphragm tweeter
  • Directivity (HxV) 90º x 90º
  • Dimensions (HxWxD): 532 x 250 x 260 mm
  • Weight: 8.7 kg
  • Finish: multilayer plywood
  • Front steel grille with foam
  • High resistant bi-component black Polyurea coating

JK10

!
  • Power (musical program): 500 W
  • Nominal impedance: 8 Ω
  • SPL (1m) 97 dB (1 W), 124 dB continuous, 127 dB peak
  • Frequency response (-10 dB): 52 Hz – 18 kHz
  • LF 10” woofer (2.5″ voice coil)
  • HF 1.4” PETP diaphragm driver
  • Directivity (HxV) 50º a 100º x 55º
  • Dimensions (HxWxD): 539 x 365 x 340 mm
  • Weight: 16.3 kg
  • Finish: multilayer plywood
  • Front steel grille with foam
  • High resistant bi-component black Polyurea coating

JK12

!
  • Power (musical program): 700 W
  • Nominal impedance: 8 Ω
  • SPL (1m) 98 dB (1 W), 126 dB continuos, 129 dB peak
  • Frequency response (-10 dB): 48 Hz – 19 kHz
  • LF 12” woofer (3″ voice coil)
  • HF 1.75” PETP diaphragm Neodymium driver
  • Directivity (HxV) 50º a 100º x 55º
  • Dimensions (HxWxD): 609 x 410 x 405 mm
  • Weight: 21.7 kg
  • Finish: multilayer plywood
  • Front steel grille with foam
  • High resistant bi-component black Polyurea coating

JK15

!
  • Power (musical program): 800 W
  • Nominal impedance: 8 Ω
  • SPL (1m) 99 dB (1 W), 128 dB continuos, 131 dB peak
  • Frequency response (-10 dB): 45 Hz – 19 kHz
  • LF 15” Neodymium woofer (3″ voice coil)
  • HF 1.75” PETP diaphragm Neodymium driver
  • Directivity (HxV) 50º a 100º x 55º
  • Dimensions (HxWxD): 689 x 460 x 450 mm
  • Weight: 22.5 kg
  • Finish: multilayer plywood
  • Front steel grille with foam
  • High resistant bi-component black Polyurea coating

JK12wa

!
  • Amplifier (program power): 500 W (LF)  – Class D
  • Input Sensitivity: 2 dBu – 1 V
  • Input Impedance: 20 kΩ
  • Maximum input level: 20 dBu
  • Mains: Universal switch mode Power Supply 85-265 V / 45-65 Hz
  • Average current draw: 0.8 A (Heavy duty musical program)
  • Standby Mode Consumption: < 5 W
  • SPL (1m) 123 dB continuous, 126 dB peak
  • Built-in DSP: 48 bit, Presets XOPOLE / LPF90 / LPF90+3 / LPF100 / LPF100+3 / LPF110 / LPF110+3/ LPF120 / LPF120+3
  • Built-in delay line: 118 ms/ 40 m
  • AD/DA converters: 24 bit – 48 kHz
  • Frequency response (-10 dB): 38 Hz – 90/100/110/120 Hz
  • LF: 12” woofer (3” voice coil)
  • Directivity (HxV): omnidirectional
  • Dimensions (HxWxD): 387 x 520 x 530 mm
  • Weight: 25.6 kg
  • Multilayer Baltic birch plywood
  • 1.5 mm optimized steel grille with foam
  • High resistant bi-component black Polyurea® coating

JK15wa

!
  • Amplifier (program power): 1000 W (LF)  – Class D
  • Input Sensitivity: 2 dBu – 1 V
  • Input Impedance: 20 kΩ
  • Maximum input level: 20 dBu
  • Mains: Universal switch mode Power Supply 85-265 V / 45-65 Hz
  • Average current draw: 1 A (Heavy duty musical program)
  • Standby Mode Consumption: < 5 W
  • SPL (1m) 127 dB continuous, 130 dB peak
  • Built-in DSP: 48 bit
  • Presets XOPOLE / LPF90 / LPF90+3 / LPF100 / LPF100+3 / LPF120 / LPF120+3
  • Built-in delay line: 118 ms/ 40 m
  • AD/DA converters: 24 bit – 48 kHz
  • Frequency response (-10 dB): 36 Hz – 90/100/120 Hz
  • LF: 15” woofer (4” voice coil)
  • Directivity (HxV): omnidirectional
  • Dimensions (HxWxD): 475 x 630 x 630 mm
  • Weight: 41.6 kg
  • Multilayer Baltic birch plywood
  • 1.5 mm optimized steel grille with foam
  • High resistant bi-component black Polyurea® coating

JK18wa1

!
  • Amplifier (program power): 1000 W (LF)  – Class D
  • Input Sensitivity: 2 dBu – 1 V
  • Input Impedance: 20 kΩ
  • Maximum input level: 20 dBu
  • Mains: Universal switch mode Power Supply 85-265 V / 45-65 Hz
  • Average current draw: 1 A (Heavy duty musical program)
  • Standby Mode Consumption: < 5 W
  • SPL (1m): 128 dB continuous, •131 dB peak
  • Built-in DSP: 48 bit, Presets XOPOLE / LPF90 / LPF90+3 / LPF100 / LPF100+3 / LPF110 / LPF110+3
  • Built-in delay line: 118 ms/ 40 m
  • AD/DA converters: 24 bit – 48 kHz
  • Frequency response (-10 dB): 32 Hz – 90/100/110 Hz
  • LF: 18” woofer (4” voice coil)
  • Directivity (HxV): omnidirectional
  • Dimensions (HxWxD): 552 x 740 x 710 mm
  • Weight: 50.9 kg
  • Multilayer Baltic birch plywood
  • 1.5 mm optimized steel grille with foam
  • High resistant bi-component black Polyurea® coating

JK18wa2

!
  • Amplifier (program power): 2000 W (LF)  – Class D
  • Input Sensitivity: 2 dBu – 1 V
  • Input Impedance: 20 kΩ
  • Maximum input level: 20 dBu
  • Mains: Universal switch mode Power Supply 85-265 V / 45-65 Hz
  • Average current draw: 2 A (Heavy duty musical program)
  • Standby Mode Consumption: < 5 W
  • SPL (1m) 132 dB continuous, 135 dB peak
  • Built-in DSP: 48 bit
  • Presets XOPOLE / LPF90 / LPF90+3 / LPF100 / LPF100+3 / LPF110 / LPF110+3
  • Built-in delay line: 118 ms/ 40 m
  • AD/DA converters: 24 bit – 48 kHz
  • Frequency response (-10 dB): 30 Hz – 90/100/110 Hz
  • LF: 18” woofer (4” voice coil)
  • Directivity (HxV): omnidirectional
  • Dimensions (HxWxD): 552 x 740 x 710 mm
  • Weight: 51.9 kg
  • Multilayer Baltic birch plywood
  • 1.5 mm optimized steel grille with foam
  • High resistant bi-component black Polyurea® coating

JK15w

!
  • Power (musical program): 1000 W
  • Nominal impedance: 8 Ω
  • SPL (1m) 98 dB (1 W), 127 dB continuos, 130 dB peak
  • Frequency response (-10 dB): 38 Hz – 200 Hz (LPF-12: LPF Xover 12 dB/oct available for passive–parallel use)
  • LF 15” woofer (4” voice coil)
  • Directivity (HxV) omnidirectional
  • Dimensions (HxWxD): 475 x 630 x 630 mm
  • Weight: 39.5 kg
  • Finish: multilayer plywood]
  • Front steel grille with foam
  • High resistant bi-component black Polyurea coating

JK18w1

!
  • Power (musical program): 1000 W
  • Nominal impedance: 8 Ω
  • SPL (1m) 98 dB (1 W), 128 dB continuos, 131 dB peak
  • Frequency response (-10 dB): 34 Hz – 190 Hz (LPF-12: LPF Xover 12 dB/oct available for passive–parallel use)
  • 18” woofer (4” voice coil)
  • Directivity (HxV) omnidirectional
  • Dimensions (HxWxD): 552 x 740 x 710 mm
  • Weight: 48.9 kg
  • Finish: multilayer plywood
  • Front steel grille with foam
  • High resistant bi-component black Polyurea coating

JK18w2

!
    Als boven maar nu in:
  • Power (musical program): 2000 W

JK218w2

!
  • Power (musical program): 2000 W
  • Nominal impedance: 4 Ω
  • SPL (1m) 101 dB (1 W), 134 dB continuos, 137 dB peak
  • Frequency response (-10 dB): 28 Hz – 110 Hz (With external DSP)
  • 2x 18” woofers (4” voice coil)
  • Directivity (HxV) omnidirectional
  • Dimensions (HxWxD): 572 x 1070 x 805 mm
  • Weight: 77.8 kg
  • Finish: multilayer plywood
  • Front steel grille with foam
  • High resistant bi-component black Polyurea coating

JK218w4

!
  • Power (musical program): 4000 W
  • Nominal impedance: 4 Ω
  • SPL (1m) 102 dB (1 W), 138 dB continuos, 141 dB peak
  • Frequency response (-10 dB): 28 Hz – 110 Hz (With external DSP)
  • 2x 18” woofers (4” voice coil)
  • Directivity (HxV) omnidirectional
  • Dimensions (HxWxD): 572 x 1070 x 805 mm
  • Weight: 78.4 kg
  • Finish: multilayer plywood
  • Front steel grille with foam
  • High resistant bi-component black Polyurea coating

Accesoires

!

fc-jk26 flichtcase 4x jk26/a

!
    Deze flightcase is geschikt voor 4 Amate Audio JK26/JK26A/JK26A+ luidsprekers

fc-jk10 flightcase 2x jk10/a

!
    Deze flightcase is geschikt voor 2 Amate Audio JK10/JK10A luidsprekers

fc-jk12 flightcase 2x jk12/a

!
    Deze flightcase is geschikt voor 2 Amate Audio JK12/JK12A luidsprekers

fc-jk15 flightcase 2x jk15/a

!
    Deze flightcase is geschikt voor 2 Amate Audio JK15/JK15A luidsprekers

fc-jk15w flightcase 2x jk15w/a

!
    Deze flightcase is geschikt voor 2 Amate Audio JK15W/JK15WA luidsprekers

fc-jk18 flightcase 1x jk18w/a

!
    Deze flightcase is geschikt voor 1 Amate Audio JK18W1+2/JK18WA1+2 luidspreker
