N12SM

Bestel
  • Beschrijving
Amplifier (program power) 600 W + 100 W Class D bi-amplified
Input Sensitivity 8 dBu – 1.94 V
Input Impedance 20 kΩ balanced
Mains Universal switch mode
Power Supply 85-265 V / 45-65 Hz
Average current draw 0.7 A (Heavy duty musical program)
SPL (1m) 128 dB continuous, 131 dB peak
Built-in DSP 48-bit processing unit. Includes factory presets.
AD/DA converters 24 bit – 48 kHz
Presets FLAT, NEARFIELD, SPEECH
Standby mode consumption < 5 W
Adjustable delay line 118 ms / 40m
Frequency response (-10 dB) 58 Hz – 19 kHz
LF – MF 12″ neodymium woofer (3″ voice coil), HF 1.75″ PETP diaphragm neodymium driver
Directivity (HxV) 50º to 100º x 55º asymmetrical
Dimensions (HxWxD) 459 x 364 x 570 mm
Connectors 1x XLR input / 1x XLR link / 1x AC PowerCon input / 1x AC PowerCon link
